Bartyr 9" Handlebar
INFO
Bartyr is the "Barspin Killer"of the handlebars
Manufactured from heat-treated 4130 CrMo double-butted tubing
But what is a double-butted tube?
A double-butted tube has two different wall thicknesses — thicker at the ends and thinner in the middle sections. This design provides greater strength where it’s most needed while reducing overall weight.
The tube keeps a constant outer diameter, but the wall thickness varies at the most critical points to improve durability.
For this reason, the crossbar usually has a smaller diameter than the main tubes.
Thanks to the double-butted construction, the handlebar features different wall thicknesses at both ends to make welding easier and the overall structure lighter and stronger.
MATERIAL
CrMo 4130 with heat-treatment
TUBING
22.2 MM - 7/8" Double Butted
CLAMPING DIAMETER
22.2 MM - 7/8"
COLORS
Black and Chrome
WEIGHT
- Black: 880 GR / 31.04 OZ
- Chrome: 860 GR / 30.33 0Z
SHIPPING & RETURNS
Orders placed before 4:00 PM (Monday–Friday)ship out the same day.
You have 15 working days from the day you receive your order to request a return.
Free shipping on orders over 80 € (availability varies by location)
GEOMETRY
RISE " R "
9"
WIDTH " W "
29"
BACKSWEEP " B "
11º
UPSWEEP " U "
2º
CLAMPING DIAMETER " C "
22.2 mm - 7/8"
bartyr 9"
